Vehicle Ultracapacitor Modules CP-58.3F-16.2V-E

DC 12V Vehicle Ultracapacitor Module

Applicable to gasoline car and diesel car.



After three-years use by owner, capacity no decline!

Ultracapacitors pass UL810A safety test- no fire, no explosion.
Conform RoHS specification- no polltion material.

Primary Applications:
    • Vehicle Ultracapacitor Module
Features:
    • UC Module can support the under current in parallel connection with lead-acid battery.



    • Instantaneous current can up to 220A/Sec.



    • The ignition effect of coil and spark plug become more effective.



    • Extend battery life.



    • High charge/discharge efficiency: charging time only 6 seconds.
Specifications:
    • Product number : CP-58.3F-16.2V-E



    • Capacity : 58.3F



    • Rated Voltage : 12V



    Maximum Voltage : 16.2V



    • ESR(AC):<18mΩ



    • Maximum Current : 220A/Sec.



    Shorte-circuit Current : 700A/Sec.



    • Cycle Life(25℃) : 500,000 times



    • Opration Temp.(℃) : -40 ~ +65℃



    Storage Temp.(℃): -40 ~ +70℃



    • Size : L*W*H 120 x 120 x 90mm (except for water-proof connector)



    Weight : 810g





    Full specification please download in the upper right corner.



    Inner insures all of products by SINGKONG INSURANCE.



    Policy number : 1305-04AKP0000560



    Maximum compensation amount : 10,000,000 TWD
