Super capacitor module CPM-2.91F-324V-A
Primary Applications:
    • Large unmanned transport
    • Small UPS system
    • Automation equipment
    • Used in motor systems to improve performance and save power
Features:
    • Ultra-high voltage does not need to be connected in series
    • Resistive balance
    • Hot plug quick connector is safer to use
    • Patented heat dissipation technology keeps the module low during operation
Specifications:
    • Capacity: 2.91F
    • Rated voltage: 324V
    • Maximum voltage: 342V
    • Internal resistance (AC resistance): <240mΩ
    • Maximum current: 170A/Sec.
    • Short circuit current: 840A/Sec
    • Operating temperature (℃): -40 ~ +65℃
    • Storage temperature (℃): -40 ~ +70℃
    • Dimensions: length * width * height 380×268×157.7mm
    • Weight: about 12Kg
